ASRock A620AM-HVS Micro ATX Motherboard for AMD AM5 CPUs
Original price was: £77.69.£71.94Current price is: £71.94. INC VAT
In stock
In stock
You Save: £5.75 (7%)
Key Features
- Chipset: AMD A620A
- Socket: AM5
- Form Factor: Micro-ATX
- Memory: 2 x DDR5
- Storage: 2 x M.2
Shipping & Delivery
-
Standard Delivery
Our courier will deliver to the specified address
5-7 Working Days
From £4.99
-
Express Delivery
DHL courier will deliver to the specified address
2-3 Working Days
From £9.99
-
Free 30-Day returns
Description
ASRock A620AM-HVS Micro ATX Motherboard – Reliable Power and Smart Design for AMD AM5 Builds
Compact Power with Next-Gen AMD Performance
The ASRock A620AM-HVS Micro ATX Motherboard is engineered to deliver outstanding stability and performance for AMD AM5 processors. With its compact design and AMD A620A chipset, it’s perfect for small to mid-sized builds without sacrificing power. Supporting DDR5 memory up to 6800+(OC) and advanced overclocking profiles, this motherboard ensures superior responsiveness and efficiency whether you’re gaming, multitasking, or creating.
Versatile Connectivity and High-Speed Storage
Equipped with dual M.2 slots and two SATA III ports, the ASRock A620AM-HVS offers flexible storage options for both NVMe and SATA devices. PCIe 4.0 x16 and PCIe 3.0 expansion slots ensure compatibility with high-performance GPUs and add-on cards. The board also includes multiple USB 3.2 Gen1 and Type-C ports on both front and rear panels, giving you fast and reliable connections for all your peripherals and devices.
Enhanced Audio and Networking Experience
Featuring 7.1 Channel HD Audio powered by Realtek ALC897, this motherboard delivers immersive, high-definition sound quality ideal for gaming and media consumption. The integrated Gigabit LAN ensures smooth and stable online connectivity. Built with quality components and backed by a 3-year replacement warranty, the ASRock A620AM-HVS is a dependable choice for builders seeking balance between power, performance, and durability.
| Motherboard Type | Desktop |
| Form Factor | Micro ATX |
| Socket | AMD AM5 |
| Chipset | AMD A620A |
| CPU Support | Click here for CPU support |
| RAM Technology | DDR5 (Dual Channel), Supports ECC/non-ECC, un-buffered memory, Supports XMP and EXPO |
| RAM Slots | 2 x DIMM |
| RAM Speeds | Up to 6800+(OC) |
| Maximum Memory | 128GB |
| Graphics | Integrated Graphics (specifications may vary between CPU types) |
| Graphics Ports | 1 x VGA, 1 x HDMI |
| PCI/PCI Express | 1 x PCIe 4.0 x16 (supports x16 mode), 2 x PCIe 3.0 x1 |
| Storage | 2 x SATA III, 2 x M.2 (PCIe 4.0 x4, SATA & PCIe 3.0 x4) |
| RAID | Supports RAID 0, 1 for SATA and RAID 0, 1, 10 for M.2 NVMe devices |
| Wireless | – |
| LAN | GB LAN |
| Audio | 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| USB Ports Supported | Rear: 4 x USB 5Gbps Type-A, 4 x USB 2.0 | Front: 1 x USB 5Gbps Type-C, 2 x USB 5Gbps Type-A, 4 x USB 2.0 |
| Back Panel I/O Ports | 2 x Antenna Mounting Points, 1 x VGA, 1 x HDMI, 4 x USB 3.2 Gen1 Type-A, 4 x USB 2.0, 1 x RJ-45 LAN, 1 x BIOS Flashback Button, HD Audio Jacks |
| Internal I/O Connectors | 1 x Power LED and Speaker, 1 x RGB LED, 3 x Addressable LED, 1 x CPU Fan, 3 x Chassis/Water Pump Fan, 1 x 24 pin ATX, 1 x 8 pin 12V, 1 x Front Panel Audio, 2 x USB 2.0, 1 x USB 3.2 Gen1, 1 x Front Panel Type-C USB 3.2 Gen1 |
| Accessories | 1 x I/O Shield, 2 x SATA Data Cables, 1 x Screw for M.2 Socket |
| Additional Features | See Overview |
| Package Type | Retail |
| Package Weight | To be confirmed |
| Warranty | 3 Year Replacement Warranty |
