Solid durability meets bold aesthetics. The ASRock B860M Steel Legend WiFi is purpose-built for everyday users and PC enthusiasts seeking reliable performance with style. Packed with high-end features, robust power delivery, and future-ready connectivity, it’s engineered for smooth daily computing and overclocked gaming alike.
Description
- Supports Intel® Core™ Ultra Processors (Series 2) on LGA1851 socket
- 12+1+1+1+1 Power Phase with 80A SPS for VCore+GT+SA
- 4 x DDR5 DIMM slots, up to 8666+ MHz (OC), dual-channel support
- 1 x PCIe 5.0 x16 reinforced steel slot
- Integrated graphics support with HDMI, DisplayPort, and Thunderbolt™ 4
- Realtek ALC1220 7.1 CH HD Audio with Nahimic enhancements
- Storage: 1 x PCIe 5.0 M.2, 3 x PCIe 4.0 M.2, 4 x SATA3 ports
- Wi-Fi 6E (802.11axe) with Bluetooth 5.3 and Dragon 2.5G LAN
- USB ports: Thunderbolt 4, USB 3.2 Gen2/Gen1, USB 2.0 (rear & front)
- High-quality power components: 2oz Copper PCB, Hi-Density Connectors, 20K Black Caps
- DIY friendly: Toolless M.2 heatsinks, BIOS Flashback, flexible I/O shield
- ARGB support with Polychrome RGB & SignalRGB integration
Specifications
| Form Factor | Micro ATX |
| Socket | Intel LGA1851 |
| Chipset | Intel B860 |
| Memory | 4 x DDR5 DIMM, Dual Channel, up to 8666+ MHz (OC), max 256GB |
| Graphics Outputs | 1 x HDMI, 1 x DisplayPort, 1 x Thunderbolt 4 Type-C |
| Expansion Slots | 1 x PCIe 5.0 x16 |
| Storage | 4 x SATA III 1 x PCIe 5.0 x4 M.2 3 x PCIe 4.0 x4 M.2 |
| RAID Support | RAID 0, 1, 5, 10 (SATA only) |
| Networking | 2.5G LAN (Realtek), Wi-Fi 6E (802.11axe), Bluetooth 5.3 |
| Audio | Realtek ALC1220 7.1 CH HD Audio, Nahimic Audio |
| Rear I/O | 1 x Thunderbolt 4 Type-C 2 x USB 3.2 Gen2 Type-A 4 x USB 3.2 Gen1 2 x USB 2.0 1 x HDMI, 1 x DisplayPort 1.4 1 x SPDIF Out 1 x RJ-45 LAN 2 x Wi-Fi Antenna 1 x BIOS Flashback Audio jacks |
| Front Panel I/O | 1 x USB 3.2 Gen2 Type-C 1 x USB 3.2 Gen1 2 x USB 2.0 headers (supporting 4 ports) |
| Internal Headers | Thermistor, SPI TPM, Power LED, RGB, 3 x ARGB, 2 x CPU Fan, 4 x Chassis Fan, AIO Pump, 24-pin ATX, 2 x 8-pin 12V |
| Additional Features | Polychrome RGB, SignalRGB, BIOS Flashback, Pre-installed LAN Driver, 20K Black Caps, Anti-Drop M.2 Screws, XXL M.2 Heatsinks |
| Accessories | 2 x SATA cables 2 x Wi-Fi Antennas 1 x Thermistor Cable 1 x M.2 Screw |
| Package Type | Retail |
| Weight | 1.535 kg |
| Warranty | 3 Year Replacement Warranty |
CPU Support List: Click here
