ASRock Z790 PG SONIC – Sonic the Hedgehog Edition
Officially licensed by SEGA, the ASRock Z790 PG SONIC motherboard features iconic Sonic the Hedgehog visuals to celebrate the release of *Sonic Frontiers*. A 16-bit spinning ring decorates the rear I/O cover, while Sonic’s silhouette and dynamic blue-silver theme capture the spirit of Green Hill Zone.
- Supports 13th & 12th Gen Intel® Core™ Processors (LGA1700)
- 12+1+1 Power Phase with Dr.MOS
- Supports DDR5 up to 6800MHz (OC)
- 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x1
- Graphics Output: HDMI, DisplayPort, eDP
- Realtek ALC897 7.1 CH HD Audio, Nahimic Audio
- 3 x Hyper M.2 (PCIe Gen4x4), 4 x SATA III
- 2 x USB 3.2 Gen2 Type-C (1 Rear, 1 Front)
- 1 x USB 3.2 Gen2 Type-A (Rear)
- 6 x USB 3.2 Gen1 (4 Rear, 2 Front)
- 6 x USB 2.0 (2 Rear, 4 Front)
- Dragon 2.5G LAN
- Wi-Fi 6E (802.11ax) + Bluetooth
- ASRock Auto Driver Installer support
Description
Specifications
| Motherboard Type | Desktop |
| Form Factor | Micro ATX |
| Socket | Intel LGA1700 |
| Chipset | Intel Z790 |
| RAM Technology | DDR5 (Dual Channel) |
| RAM Slots | 4 x DIMM |
| RAM Speeds | Up to 6800+(OC) |
| Max Memory | 256GB |
| Graphics | Integrated Graphics* *Graphics support depends on CPU |
| Graphics Ports | 1 x HDMI 1 x DisplayPort 1.4 1 x eDP 1.4 |
| Expansion Slots | 1 x PCIe 5.0 x16 1 x PCIe 4.0 x1 |
| Storage | 4 x SATA III 3 x M.2 (PCIe Gen4x4) |
| RAID Support | RAID 0, 1, 5, 10 (SATA only) |
| LAN | 2.5G LAN |
| Wireless | Wi-Fi 6E (802.11ax) Bluetooth Dual-band 2×2 MU-MIMO support |
| Audio | Realtek ALC897 7.1 CH HD Audio Nahimic Audio |
| Rear USB Ports | 1 x USB 3.2 Gen2 Type-C 1 x USB 3.2 Gen2 Type-A 4 x USB 3.2 Gen1 2 x USB 2.0 |
| Internal USB Headers | 1 x USB 3.2 Gen2 Type-C (Front) 2 x USB 3.2 Gen1 4 x USB 2.0 |
| Back Panel I/O | 2 x Antenna Ports 1 x PS/2 Mouse/Keyboard 1 x HDMI 1 x DisplayPort 1.4 1 x USB 3.2 Gen2 Type-A 1 x USB 3.2 Gen2 Type-C 4 x USB 3.2 Gen1 2 x USB 2.0 1 x RJ-45 LAN Audio Jacks |
| Internal I/O | 1 x eDP Signal 1 x SPI TPM 1 x Chassis Intrusion & Speaker 1 x RGB LED 3 x Addressable LED 1 x CPU Fan 1 x CPU/Water Pump Fan 3 x Chassis/Water Pump Fan 1 x 24-pin ATX 2 x 8-pin 12V 1 x Front Panel Audio 2 x USB 2.0 Headers |
| Accessories | 1 x User Manual 2 x SATA Cables 2 x Wi-Fi Antennas 3 x M.2 Screws 2 x M.2 Standoffs |
| Package Type | Retail |
| Package Weight | 1.6 kg |
| Warranty | 3 Year Replacement Warranty |
